Current	100A 30A 40A 50A 60A

Descripción
Comentarios de clientes(0)

Item specifics

Brand Name EASUN POWER
Certification NONE
Origin CN(Origin)
Model Number ICharger MPPT L30/40/50/60/100A
Is Smart Device YES
is_customized Yes
Application Charger Controller
Application Solar System Controller
Application Voltage Controller
Application Solar Working Station
Application Lighting Controller
Maximum Current 100A
Maximum Current 30A 40A 50A 60A 100A
Maximum power current 100A
Application Solar System Controller
Max. PV voltage 50V
Charing Model MPPT+PWM
Max. PV input power 750W(12V) / 1500W(24V)

Product Description

Function:

1. Always keep the battery on fill voltage condition.2. Prevent the battery from over-charging.3. Prevent the battery from over-discharging.4. Prevent the battery from reverse charging to solar panels duringnights.5. Reverse Polarity Protection for Battery6. Reverse Polarity Protection for Solar Panels7. When the battery voltage is low, the controller willautomatically cut off the load from the system. If the voltage ofbattery is back to normal and the load will restart working.8. Thunder protection9. According to the battery voltage grade, the controller canautomatically set charge-off voltage, the load-off voltage, theload- restore voltage. (The parameter is default under 25℃condition, locked by the CPU procedure, cannot adjust.)10. The controller will automatically compensate the temperature ofthe charging voltage according to the changes of ambient temperature.

Features:

1. Industrial-grade master chip, 16 AD sampling accuracy, temperature, charging current,discharge current accurate real-time display, power generation at a glance.2. Automatic focusing MPPT tracking charging, high charging efficiency, non-stop detectionduring charging, bidirectional focusing tracking.3. Large-screen LCD display, adjustable charging and discharging parameters. UItra-wide chargeand discharge adjustable, as long as you understand the characteristics of the battery set itscorresponding charging parameters, you can charge a battery. When the output is off, the timecan be adjusted, which is more convenient. (on the market, there is no point adjustment)4. Acomplete three-phase charge management, effectively protect the battery, the battery is moredurable.5. Built-in overheating, overcurrent short circuit, open circuit protection, reverse connectionprotection,when the fault is eliminated, the controller automatically recovers, does not damagethe device.6. Bidirectional MoS tube anti-backflow circuit, high-power charging mode, ultra-low heat.7. R5. 0 solar charging DC plug, R5. 0 DC lamp output DC plug, convenient connection.

Note:It is high quality compatible MPPT + PWM Solar Controllers ,not 100% Ture MPPT

Specifications1. Rated voltage: 12/24V2. Rated current: 30/40/50/60/100A3. Max. PV input power: 750W(12V) / 1200W(24V)4.System voltage: 12 / 24V adaptive
5.Rated charging current: 30A | 40A | 50A| 60A | 100A
6.Rated discharge current: 10A | 20A | 20A | 30A | 30A
7.Solar photovoltaic voltage :12V battery with 18V solar panel, 24V battery with 36V solar panel
8.Full Voltage Value : Lithium Battery (12.2V) | B02 Colloidal Battery (14.2V) | B03 Open Cell (14.6V)
9.Floating Charge Voltage : 13.7 V ( Default, Adjustable )
10.Discharge cut-off voltage::10.7 V ( default, adjustable )
11.Discharge recovery voltage: 12.6 V ( default, adjustable )
12.Standby current :10mA
13.USB Output : 5V / 2A MAX
14.Operating temperature:- 35 - 60Package Includes：1 x Solar Panels Battery Charge Controller1 x User Manual
