Item specifics

Certification CE
Origin CN(Origin)
Model Number HA01
is_customized Yes
Application Voltage Controller
Usage lead acid battery

Product Description

battery equalizer for 12V lead acid battery connected in series:

Battery equalizer HA01 is used for the lead-acid batteries which are connected in series to keep battery voltage balance.

When two or more in-series connected batteries are in charging/discharging/free status. The battery voltages maybe become different. One battery voltage is high and one is low.

The battery equalizer will equalize/balance the battery voltage when it detect there are 20mV between two batteries. It will shunt current from one battery (the higher voltage one) to the other battery (the lower voltage one). Until their battery voltage almost becomes same. This will improve battery’s performance and extent battery’s life time.

Battery equalizer can be used for 24V, 36V, 48V and any other N*12V battery system.
1 piece for 24V system;
2 pieces for 36V system;
3 pieces for 48V system;

............

TECHNICAL DATA

Battery nominal voltage /	2*12V
Optimizing current /	0-5A(balance current based on batteries voltage difference)
Quiescent current	<3mA
Size	707027 mm
Protection	Reverse polarity protection
Low voltage disconnect	10V
