Item specifics

Brand Name TOPGNSS
Origin CN(Origin)
Model Name GNSS100L
GPS type Receiver & Antenna
Chipset: GNSS multimode chip M8030-KT
Support: GPS+GLONASS+GALILE0
Output: USB protocol
Cable length: 3M (default)
Waterproof level: IP67
Fixed: Magnet
Baud rate: 9600 (default)
Working voltage 5V
LED status indication: positioning LED after flashing

Product Description

Store special sales promotion 300PCS TOPGNSS.store sales promotion, Only once a year, Rare opportunity s，atisfaction, please give us 5 points of evaluation! Default working mode: GPS+GLONASS+GALILEO (Optional settings: GPS+GLONASS+GALILEO) USB Cable length: 1.5 meters GNSS receiver GPS GALILEO GNSS100L TOPGNSS

GNSS receiver GPS GALILEO GNSS100L TOPGNSS

usb GNSS GPS GALILEO Receiver gnss100L topgnss

Applications Track record of data acquisition Automatic vehicle location Driving recorder Navigation GPS clock and digital camera Child/elderly/personal locator and security system Features Multi-satellite positioning systems support GPS/QZSS/GLONASS/GALILEO(GNSS100L) GPS/QZSS/Beidou Sensitivity Acquisition: -148dBm Tracking: -167dBm Low power: 40mA at continuous tracking SBAS (WAAS, EGNOS, MSAS) support Higher update rate option (default 1Hz) RTCM 2.3 4.X support A-GPS support, OMA SUPL/3GPP TS25.171 (GSM/UMTS) compliant Easy to use: built-in patch 25*25*4mm antenna Backup battery support for faster position fix LED for position fix indication Windows location sensor support GNSS RECEIVER GNSS100g

Support PC system: XP VSTAR WIN7 WIN8 win10 Set 10HZ output, dynamic test precision in open zone

Receiver Type	72-channel 8030 engine GPS & QZSS:L1 C/A,1575.42MHz, GLONASS L1OF, 1598.0625~1605.375MHz GALILEO/BEIDOU B1 1561.098 MHz SBAS: WAAS, EGNOS, MSAS
Horizontal	2.5m (Autonomous)
Position	2.0m (WAAS)
Accuracy	(including SBAS & QZSS; CEP, 50% 24hr static, -130dBm, >6 SVs)
Velocity	0.05 m/s (speed)
Accuracy	<0.3(heading) (50%@30m/s)
Time Pulse	30ns (RMS)
Signal Accuracy	<60ns (99%)
Time Pulse Frequency	0.25 Hz ~ 10 MHz
Time To First Fix Hot start Cold start	Autonomous 1.5 sec 26 sec (50% -130dBm)
Sensitivity (Autonomous)	-148dBm (acquisition) -167dBm (tracking)
Navigation. Update Rate	Max. 10Hz, GPS & GLONASS or GPS & Beidou Max. 18Hz, GPS only Default 1Hz
Max. Altitude	50,000 m
Max. Velocity	<1,852 km/hr
Protocol Support	NMEA 0183 v2.3 and V4.x UART: 9600 bps N,8,1; GGA, GLL, GSA, GSV, RMC, VTG, TXT
SBAS Support	WAAS, EGNOS, MSAS

gps galileo receiver

- USB GNSS RECEVER driver and test star software, can be downloaded from our server. (we have more than one version of the test software can choose)
- You encountered in the use of any questions or you need to buy more quantity, please contact with us We can provide professional OEM or ODM services
