Waterproof IP65

Case to ensure stable operation in tough environment.

Wide Application

Vehicle Rental, Logistics, Motorcycle, Bus Management

Long Standby Time

Built-in 3.7V 10000mAh Li-ion battery, it can standby time up to 120 days.

Powerful Magnetic

Built-in 6pcs magnets with super strong powerful magnetic, can be very easily installed on vehicles and assets.

Shake Alarm

After you did the shake alarm setting please keep the tracker being stationary for 5 minutes, then this function will start working. It will send SMS "sensor alarm!" to the admin number when the unit get shock.

Over-speed Alarm

This alarm works only under continuous positioning mode. When the unit speed you presetted, it will send message "speed alarm!" to the admin number every 5 minutes.

Remotely Voice Monitor

You will can remotely monitor the voice around the device, everything is under your eyes.

Sleep Mode

Sleep by time: Example : if the time configured time interval in 5 minutes, then the tracker will work for 5 minutes after being waked up, and then back to sleep mode. SMS command, calling tracker can wake up the tracker.

Sleep by shock: if no shock within 5 minutes, then the tracker will enter into sleep mode, it can be wake up by shock, SMS command, calling.

If you want to close the sleep mode , please send SMS command： sleep123456 off

Loosing Alarm Setting

There is anti-removal induction sensor on the back of the device. If this covered induction sensor is not covered again, it will send "Loosing Alarm" to admin number and SOS number by SMS.

Geo-fence

You can set up a safety virtual zone, if your target go out or enter in this area, this tracker will send alarm information to you.

Admin Account

I can help you set an account,You can manage multiple devices simultaneously in one account.

History Route Playback

User can track the history route of the device up to 6 months via both the Web and APP.

About Web tracking platform:

Free Web tracking software,no charge fee,login page : www.mytkstar.net
Select "Log in by IMEI" on the bottom of screen
IMEI No. : on the back side of cover
Password: 123456

About Mobile APP Android/IOS Tracking:

Scan the QR Code to install the applications on your cell phone.Register and add account.
Search "TKSTAR GPS" in the Apple App Store/Google Play Store or Scan the QR Code to install
the applications on your cell phone.

Overview:

Working based on existing GSM/GPRS network and GPS satellites, this product can locate and monitor any remote targets by SMS, APP and Internet. It adopts the most advanced technology of GPS and AGPS dual positioning.

Features:

1. Long Standby Time: It has built-in 3.7V 10000mAh Li-ion battery, can standby up to 120 days.
2. Powerful Magnetic: It has 6pcs built-in magnets,with super strong powerful magnetic,can be very easily installed.
3. Remotely Voice Monitor: Send "Monitor+Password" to the device first, then the device will turn into monitor mode, now if you make call to the SIM number in the device, it will pick up your call automatically and you will can monitor the voice around the device!
4. Overspeed Alarm: This alarm works only under continuous positioning mode.When the unit speed is exceed the speed you presetted, it will send message “speed alarm!” to the admin number every 5 minutes.
5. Shake Alarm: After you did the shake alarm setting,please keep the tracker being stationary for 5 minutes, then this function will start working. It will send SMS “sensor alarm!” to the admin number when the unit get shocked.
6. Sleep Mode:
* Sleep by time mode: After did this setting, tracker will only work for 5 minutes after being waked up, and back to sleep mode, GPS will shut off and GSM will works in low consumption mode. SMS, call will can wake up the tracker.
* Sleep by shock sensor mode: After did this setting, if no shock for 5 minutes, the tracker will work under "sleep by shock" mode, GPS will shut off, GSM will works in low consumption. Vibration, SMS, call will can wake up the tracker.
7. History Route Playback: You can track the history route of the device up to 6 months via both the web platform and APP !
8. Loosing Alarm
There is anti-removal induction sensor on the back of device. if this covered induction sensor is not covered again.it will send "Loosing alarms!" to admin number and SOS number by SMS.

Specification:

* Dim: 112 * 77mm * 27mm (4.41"*3.03"*1.06")
* Weight: 300 g
* Network: GSM/GPRS
* Band: 850/900/1800/1900Mhz
* GPS sensitivity: -159dBm
* GPS accuracy: 5m
* Wall charger: 110-220V input 5V-1A output
* Battery: Chargeable 3.7V 10000mAh Li-ion battery
* Stand by: 120days
* Storage Temp.: -40°C to +85°C
* Operation Temp.: -20°C to +55°C
* Humidit: 5%--95% non-condensing

Important Notice:

* This device just can work with 2G GSM network, and this item will not include Sim Card,please buy it from your local.
* Please make sure the GSM SIM card supports making calls, sending messages, GPRS network
* Please make sure the GSM SIM card has sufficient balance.
* Please make sure the GSM card has opened the call ID display function and turned off the call transfer.
* Please insert the GSM SIM card into the device correctly.
* Please use the normal SIM card for the tracker, not Micro SIM or Nano SIM.
