Feature:

1. This Mini NVR suppor 3MP/5MP Wireless IP Camera, Support 8MP 4K IP Camera;

2. Support human form detection and face detection;

3. Support h.265ai / h.265 + (compatible with h.265 / H.264) video compression technology;

4. Support onvif protocol and access to third-party backend / platform;

5. Support Wifi / Wired IP Camera, built-in Micro SD card slot,Support SSD port, maximum support 128GB Micro SD card and 8TB 2.5“HDD (optional at the time of purchase)

6. Supports 7x24 hours loop recording, motion detection recording, and other recording modes, you can playback the recording to view;

7. Support web side, CMS, central management platform software XMEYE;

8. Supprt Cloud technology,Realize network penetration, front and rear end docking, and push alarm information to mobile phones

Packing List

1* 8CH WIFI NVR
1* Power Adapter
1* USB Mouse

ChannelType of 8CH

1. Max support 8*3MP IP Camera,or 4*5MP IP Camera

2.Support mixed access of wired IP Camera and WIFI Camera;

3.Playback 4CH 5MP/ 8CH 3MP

4.If Your camera is Wird 4K camera, it will support.

Here wifi camera must ask us, if you can not sure weather Camera can work, Please send your camera Version image.

Please make order Before we confirm it work.

If your camera is wired IP camera support ONF or NETIP, it will work.

Face Record/Face Detection/Face Playback

Record every face that appears on the lens, without missing any details.
You need use the Face Detction Function IP Camera

(Your Camera Must support XM Face Detection, or will not work)

Alert area

AI Humanoid Motion Detection & Email Alert/Record

When motion is detected, the NVR can send email or start record to the hard disk without missing any important events.

(Note:(Your camera must support XM human detection, or will not work)

Multi Languages:

English,Russian,Italian,Portuguese,Spanish,French,Germany.,etc...Total 28 languages

Real Two Way Audio

Built-in microphone and speaker / Customized new speakers with loud volume .
You could talk to anyone nears the camera ( Warn someone to leave your house )

One click selection Wired or Wireless configuration, the operation is very easy and convenient,please check the screenshot as below:

Support ONVIF

you can connect any brand's Onvif IP Cameras to our this NVR;

Reminder:

Smar's Video Recorder all support ONVIF and NETIP Protocol;

Netip: It is a Private protocol, only applicable to Network Video Products of XM Scheme；

Onvif: It is an international open network video product standard network interface protocol；

Onvif Advantages:

Onvif likes a communication bridge, It can implement multiple devices(IP Camera and Video Recorder) from different manufacturers connected to each other, mutual Communication.

Onvif Disadvantages:

The standards of onvif protocol are also different for video network products of different manufacturers;

So,Their communication with each other will cause some bad problems, such as: motion detection can not work normally; Audio and video can't be synchronized; Loss of video data, etc......

(Note: We recommend that when you buying the Network Video Recorder, also buying the IP Camera from our store, Because they have perfect private protocol between them, it can fully display products all of the functions.)

Easy access via multi-platform

Support Mobile Phone iOS, Android System，Remote view of mobile phones, any time... any where...

Easy connection

NVR Size and Multi angle display:

Advanced H.265++ Video Compression

H.265 (HEVC) doubles the coding efficiency compared with its predecessor H.264. That means H.265++ video saves around 70% of the bit rate at the same quality of coding.

Support 2.5"SSD Interface

Easy remote access Anytime anywhere

P2P technology supports remote access on the mobile device,Just intall the APP on your phone by scanning the QR cade or storing from the APP View the camera remotely anytime, any where. PC use the www.xmeye.net to visit the camera.

How to manage the cameras through PC client?

1. Please used your mobile phone to scan the QR code as below, and then click to download；

2. Please install VMS software on your computer, then login VMS Software, Username: admin, Password:admin

3. Please click the Device Manager-IPV4 Search-choose address of IP Camera- ADD-SAVE,Search and Camera successfully;

4. Click t he Live View, then click IP Address of Default Group, then you will can Watching Video.

How to confirm which camera support this Wifi NVR ?

1: Wired IP camera

    Support Netip and ONF protocol IP Cameras.

    For Wired IP camera only recommend use RJ45 cable contact NVR to Router.

2: iCSEE Wifi Camera

    iCSEE camera have orgional camera and OEM camera difference, You need confirm which kind it is first.

    For orgional camera, only use the "code for Wireless" to search camera, all will be automatic contact.

    For OEM Cameras, You need press the "code for wireless"first, after search finished, press "wired configuration"to search     the camera address again, then add the camera by Hand.

    Defult will be ONF protocol, you need edit it to NETIP and "34567"port.

3: Other APP name Wifi Camera

This Kind of camera must contact seller ask first, Make sure they can work with eachother then buy it.
