NOTE

The Wi-Fi switch does not have dimmer function (except for dimmer switch) whether you connect a bulb with dimmer function or not. It can only control the opening and closing of lights.

NOTE
1. Support most of lamps. We suggest to use over 5W LED lamp for L1. Not support dimmable lamp.
2. The capacitor must be connected with L and N of the lamp of L1 tightly, not behind the switch.

RF 433MHz remote control

The smart wifi switch can be paired with any 433Mhz radio frequency transmitter. Even if there is no wifi signal at home, the device can still be controlled by the radio frequency transmitter.
(Buy 6 switches at a time, the system will automatically send an additional 10-key remote control)

Main Features:

1. The relay scheme is more stable (there is a relay inside, which is more stable than the switches on the market, has a longer service life and is more stable). Ordinary switch SCR control is easy to burn out, high-quality relay, anti-pulse voltage, anti-lightning.
2.433MHz RF Remote Control:This smart switch could be used with 433mhz RF transmitter. Control range: ≤15M.
3. The low light indicator design will not interfere with family rest, and the dark environment is easy to find and not dazzling.
4. [Wiring mode]: neutral fire + single fire general design, any family can use (with or without neutral wire can be used)
5. Only use high-end crystal tempered glass panels. Good light transmission performance, pure color, rich color, beautiful and smooth, taking into account the two effects of day and night, long service life, and does not affect use.
6.Has timer/scene control
7. Share with family for common control
8. Use with Amazon Echo and Google Home and Tmall Genie

Switch parameter

Operating Voltage:AC 110-240VAC 50/60Hz
WIFI Standard:IEEE 802.11 b/g/n
Support App:Tuya or Smart Life
Voice Control:Google Home Amazon Alexa Tmall Genie
Load Power:600W/Gang
Maximum current:10A
Power Consumption: ≤0.5W
Working Temperature: 0℃~40℃
RF Frequency: 433MHz
WIFI Standard: IEEE 802.11bgn 2.4GHz
Network Security: WPA/WPA2”
Hub requirement: No
Control Mode: APP/RF/Manual

RF 433HMZ Control

Can be paired with products carrying rf 433mhz for remote use.

Two wiring methods

Neutral wire and live wire and single live wire can be connected

We are more stable

It is equipped with a relay inside, which is more stable than the switches on the market and has a longer service life.

Slight Light indicator
Don't disturb sleep, enter to make you safer in the dark

voice control

Works perfectly with Amazon Alexa,Google Home,

Timing Function

Set the time to turn on the light.
Set time to cook rice...

Countdown function

You can set a countdown for humidifiers, microwaves, coffee machines and more. The device will stop automatically. Don't worry about the device working all the time

Two indicator colors

Soft lighting, on: red light / off: blue light

Family Sharing Control Fun

main account has the exclusive permissions,one click to share the permissions with the whole family.let the family enjoy the fun of smart life!

How to add device to mobile app

Pairing 433mhz method

1.Why is the device unstable on the app?
1. Each router having the connection limited, but more and more smart device working on family
2. A lots family still using very old version routerseven more than 3years ago version.
In order to have excellent experience, the suggestion is :
1. re-set the router connection limited
2. change a new update version router
3. please note these switch only work on 2.4G wi-fi network, not 5G.
2. Why the APP can’t find the device in pairing status?
That’s because of your phone’s cache. Please close the WLAN of your phone then open it after a minute. At the same time,please power off the device if you can, then power up to try again.
3.other problems
First suggest to view the instructions. If you still have problems, please
