Item specifics
-
Brand Name
USAFEQLO
-
Origin
CN(Origin)
-
Smart home platform
Other
-
Certification
NONE
-
Technology
Network
-
Supported Operating Systems
Microsoft Windows 2000
Microsoft Windows XP
Mac OS
Microsoft Windows 98
Microsoft Windows 7
-
e-Cloud(P2P)
Yes
-
Video Output
1CH HDMI-compatible 1920X1080 60Hz
-
IP Mode
Static IP address
-
Video Standard
NTSC
PAL
-
Hard Drive Size
3.5''
-
Network Protocol
SMTP
FTP
HTTP
DHCP
DNS
TCP/IP
UPNP
PPPoE
DDNS
-
Network Interface
RJ45 10/100M
-
Backup Type
Hard Drive
-
Audio Output
None
-
Video Input Interface
RJ45
-
Supported Mobile Systems
Windows Mobile
iPhone OS
Android
-
Two-way Audio
NO
-
Compression Format
H.265
H.264
-
Wireless Security
WEP
-
Audio Compression Format
G711A
-
Hard drive Interface Type
SATA
-
Communication Interface
None
-
Model Number
NBD80X09S-KL
-
Alarm Action
Email Photo
Local Alarm
-
POE
None
-
Audio Input
1 RCA
-
Main processor 4CH
Hisensor
-
Display
1920X1080P
-
Video output
1ch VGA
1ch HD
-
HDD Connector
1 SATA ports(each max to 8TB)
-
USB
2* USB 2.0
-
Power supply
12V2A(not include)
-
CMS
Support
-
Support Camera
Max 4K
-
Video compression
H.264/H.265
-
Package
Main PCB+SATA cable
1. HDD question: We recommend use the Newest HDD. Use the security HDD will work more better. PC HDD most can not work. 2.IP Camera 264 and 265 question: This one only support the xmeye IP camera H.265, if you use the dahua or hik camera, nvr will not match all of their cameras and not support h.265 3. VGA and HD question: NVR have a defult display resolution,Your monitor must use the same resolution then will work first time. The second you can change the nvr output resolution as you need.
Face Record/Face Detection/Face Playback Record every face that appears on the lens, without missing any details. You need use the Face Detction Function IP Camera
Langauages: English,Russian,Italian,Portuguese,Spanish,French,Germany.,etc... Total 24 languages
Motion Detection & Email Alert/Record when motion is detected, the NVR can send email or start record to the hard disk without missing any important events.
Max Support the 1080P Display
Advanced H.265+ Video Compression H.265 (HEVC) doubles the coding efficiency compared with its predecessor H.264. That means H.265+ video saves around 70% of the bit rate at the same quality of coding.
Easy remote access Anytime anywhere P2P technology supports remote access on the mobile device,Just intall the APP on your phone by scanning the QR cade or storing from the APP View the camera remotely anytime, any where. PC use the www.xmeye.net to visit the camera.
Support 9CH 4K IP Camera
Interface Definition
|
Model |
NBD80X09S-KL |
System |
Main processor |
XM8536D |
Operating System |
Embedded Linux |
System resources |
Simultaneous multi-channel real-time recording, playback, network operation, USB backup |
Interface |
Operator interface |
16-bit true color graphic menu operation interface, support mouse operation |
Preview |
1/2/4/6/8/9 |
Video |
Video input (IP) |
9*4K Unreal-time(Access bandwidth 60Mbps) |
Video compression |
H.265AI/H.265+(compatible H.265/H.264) |
Display quality |
Max:1920*1080 |
Playback quality |
4K/5M/4M/3M/1080P |
Decode |
1ch4k/1ch5M/1ch4M/2ch3M/3ch1080P |
VR |
support |
human shape / Face |
Support(depend on camera) |
Audio |
Audio compression |
G.711A |
Intercom |
support |
Record&playback |
Recording mode |
Manual>Alarm>Dynamic Detection>Timing |
Local payback |
1ch4k/1ch5M/1ch4M/2ch3M/3ch1080P |
Search mode |
Search by Time/Calendar/Event/Channel/Face |
Record storage |
HDD、Network |
Backup mode |
Network backup, USB hard disk, USB burner, SATA burner |
External interface |
Video output |
1ch VGA,1ch HDMI HD output |
Audio I/O |
1/1(3.5mm) |
Alarm I/O |
0/0 |
Network interface |
1*RJ4510M/100MAdaptiveEthernetport |
USB interface |
2*USB2.0 ports(one USB extension interface is reserved) |
HDD |
1* SATA(Up to 14TB for each disk) |
ESATA |
No |
Serial interface |
No |
Other |
|
|
Power supply |
12V/2A |
Power Consumption |
<10W(Without HDD) |
Work environment |
Temperature:0℃ -55℃, Humidity:10%-90%RH , Atm:86kpa-106kp |
Dimension |
118mm*46mm |
Weight |
A total of about 63g |
New Style Win10 Menu
