Specifications

• Rated Power: 2500W

• Surge Power: 5000W

• DC Input Voltage: 12V

• AC Output Voltage: 220V~240V

• AC Output Frequency: 50Hz

• AC Output Waveform: Pure Sine Wave

• USB Output: DC 5V/2.1A

• Waveform distortion: THD<3% (Linear load)

• Efficiency (＞90% Load): ＞90%

• DC Input Voltage Range: 10.5V~15V

• Input Low voltage Shutdown Voltage: 10V±0.3V

• Input High voltage Shutdown Voltage: 15.5V±0.3V

• No Load Current: < 1.9A

• Surge Power Duration: 0.1S

• Net Weight: 3.6 kg

• Dimensions (L x W x H): 34x17x9 cm

• Battery Cable (Cross-sectional area*length): (16mm²x500mm)x2

• Fan Starting Temperature: ≥ 45 ℃

• Temperature Protection: 75 ℃

Features

- High quality DC to AC pure sine wave.

- The main control chip adopts high-speed and stable MCU, intelligent control, real-time monitoring, AC output frequency is more accurate, and the work is more stable.

- Driven by unipolar SPWM, the output sinusoidal waveform is purer, THD<3%, lower electromagnetic interference.

- Multiple protection functions: input low voltage shutdown protection, input high voltage shutdown protection, battery high and low voltage alarm, overload protection, overheating protection.

- Automatic reset function: When input high voltage or low voltage shutdown, the inverter will automatically restore the output voltage after the input voltage returns to normal; When overheating protection, the inverter will automatically restore the output voltage after the internal temperature of the inverter is lowered.

- Safety isolation: input and output isolation.

- Soft start function, it is easier to run inductive and capacitive loads.

- Buzzer reminder device, once the protection of the inverter is triggered, the buzzer sounds an alarm to remind people.

- Anodized aluminum case, which not only has a beautiful appearance, but also has good heat dissipation performance, wear resistance, insulation, and durability.

- Intelligent temperature control fan to reduce unnecessary waste of battery power; When the internal temperature of the inverter is ≥45±5°C, the fan starts to work.

- Remote control function, can display battery power, battery low-voltage alarm, the switch button can turn on/off the inverter, the remote control port is standard RJ45, you can replace longer cable to increase remote control distance.

- Dual USB ports, output voltage 5V, maximum current 2.1A, can charge mobile phones and tablets.
