RM1307731645734439

Working voltage 6V-60V
Output Voltage :Linear
Maximum current :30A
Continuous current 20A
Speed range 0% - 100% (can be set)
Slow start and stop 0-10 seconds can be set
Speed control mode:touch-tone
Speed type: adjust Current
Support motor brush motor
Speed display :0-100%
Main board size is 85mm*58mm*38mm
Product net weight 120g
Product PWM frequency: 21KHZ

Slow start time setting Function 1: 000 - 100 Slow start to 100% Speed time adjustable between 0-10 seconds Default is 1 second.

Slow stop time setting Function 2: 000 - 100 Slow stop time is adjustable between 0-10 seconds Default is 1 second.

Speed lower limit setting function 3: 000 - 080 The minimum speed is between 0-80% adjustable and less than the maximum speed setting The default is 0.

Speed upper limit setting function 4: 000 - 100 The maximum speed is adjustable between 0-100% and greater than the minimum speed setting The default is 100%.

Acceleration and deceleration value setting Function 5: 001 002 005 010 015 020 025 Each time you press the plus/minus key, the speed changes correspondingly by 1%, 2%, 5%, 10%, 15%, 20%, 25%.

Note: The input voltage must be equal to the rated voltage of the motor.
